LED Recessed light sphere DL322 series, 12W, 3000K, 60°, black

DL322 is a spherical downlight with oblique axis rotation. It has 340 degrees of free rotation and can be adjusted to a maximum of 40 degrees for oblique illumination. Its elegant appearance and wider installation options are suitable for more and more application areas.

Uses: Cafés, Commercial spaces, Corridors, Galleries, Hotels, Indoors, Living spaces, Museums, Offices, Restaurants, Showrooms

Colour	black
Material	Aluminium, PVC
Measurements	Ø172x100mm
Cutout size	150-160mm
IP class	IP20
Socket
Beam angle	60°
Power (W)	12
Input power (V)	220-240V
Supply block	Flicker free
Frequency	50Hz
PF	≥0.9
CRI	≥80
Dimmable	No
LED module	CREE COB
CCT	No
Luminaire’s efficiency (lm/W)	100
Energy class	F
Colour temperature (K)	3000K
Luminaire lifespan	50 000h
Operating temperature	-20°C ... +45°C
Installation type	Recessed
Certificates	CE, RoHS, SAA
Warranty	3 years
Brand	UPSHINE

UP-SHINE SPEC of CL102A-2.5-8W

Download file

TL322B-12W-DA-3000K-60°

Download file
